GALI-S66-D+

The GALI-S66-D+ is ideal for radar systems, leveraging its DC to 50 GHz frequency range to support high-resolution imaging and detection in defense and aerospace applications. Its low noise feature makes it a top choice for receiver front-ends in satellite communications, ensuring clear signal amplification even in noisy environments.

In test and measurement equipment, this MMIC amplifier excels in signal chains for 5G infrastructure and IoT devices, providing high gain with compact die form for space-constrained designs. It enhances performance in RF systems requiring reliable amplification from DC to 50 GHz, such as in automated test benches and portable communication devices.

• 制造商产品型号: GALI-S66-D+
• 制造商: Mini-Circuits
• 功能类别: MMIC芯片 Monolithic Amplifiers, Die, DC to 50 GHz
• F Low (MHz): DC
• F High (MHz): 3000
• Gain (dB) Typ.: 18.2
• Power Out (dBm) @ 1dB Comp. Typ.: 3.3
• NF (dB) Typ.: 2.4
• IP3 (dBm) Typ.: 19.1
• Input VSWR (:1) Typ.: 1.1
• Output VSWR (:1) Typ.: 1.2
• DC Voltage (V): 3.5
• DC Current (mA): 16
• Features: Low Noise
