PHA-102-D+

This MMIC chip is perfect for high-frequency communication systems, such as satellite transceivers and radar modules, where its ultra high dynamic range and low noise figure ensure reliable amplification of weak signals with minimal distortion, enhancing overall system performance in harsh environments.

Additionally, the PHA-102-D+ excels in test and measurement equipment, providing high gain and linearity in signal generators and spectrum analyzers for precise RF signal analysis, making it indispensable for engineers working on advanced RF and microwave applications.

• 制造商产品型号: PHA-102-D+
• 制造商: Mini-Circuits
• 功能类别: MMIC芯片 Monolithic Amplifiers, Die, DC to 50 GHz
• F Low (MHz): 50
• F High (MHz): 6000
• Gain (dB) Typ.: 14.5
• Power Out (dBm) @ 1dB Comp. Typ.: 26.4
• NF (dB) Typ.: 3.4
• IP3 (dBm) Typ.: 50
• Input VSWR (:1) Typ.: 1.5
• Output VSWR (:1) Typ.: 1.32
• DC Voltage (V): 9
• DC Current (mA): 192
• Features: Ultra High Dynamic Range
• 想获取PHA-102-D+的更多功能参数资料?请在本页面右侧在线下载技术资料
